MOV Valves

MOV Valves


    GATE/ BALL/ BUTTERFLY etc.

Sizes:

Up to 88”









Pressure:

150 lbs. up to 2500 lbs.









Standards:

API6A, API6D, API600,

API602,API 6FA, API 598,

BS,MSS, ANSI,ASME,

ASTM,DIN, ISO 10497,

ISO 14313

Materials:

Body: 316L, A105, A743 CA6NM, ALLOY 255, B564 06600, C12, C12A, C5, CD3MN, CD4MCU, CE3MN, CF10,

CF10M,CF3, CF3M, CF8,CF8C, CF8M, CG3M, CK-3MCUN, CN7M, CU5MCUC, CY40, F-316 F-316L, F-321, F-53,

F-91, G4A,HASTB, HASTC, HASTC22, INC625,LC2, LC3, LCB, LCC, LF2,M35-1, TI-C2, TIGR2, TI-GR7,

TI-PD7B, UNS J92205,UNS N08028, UNS N08904, UNS S31803, UNS S32750, WC1, WC6, WC9, WCB, WCC

Bolting: A193 Gr. B7/ B7M, A194 Gr. 2H/ 2HM/ 7, A320 Gr. L7/ L7M, A194 Gr. 7/ 7M

Seat & Seals:

Seats: PTFE, NYLON, PEEK, NBR, KELF, Electrolysis nickel plating / Hard chrome / Tungsten carbide

Seals: BUNA-N / EPDM / VITON / Flexible graphite / FKM / HNBR / Nitrile / Neoprene

Body seals: Graphite/ Spirally-wound SS304/ 316 with Graphite Filler

End connections:

Flanged ends

Actuation:

Electrical Motor

Salient Features:

Valve maintenance possible without removing it from the pipeline

Top entry / easy access to the seat, plug, and bellows after removal of the actuator

extended bonnet for cryogenic

Actuator with additional hand wheel

Digital control element

Various types including Gate/ Ball/ Butterfly etc.
